Kafka Series, Part 4: Reliability & Operations

Replication, in-sync replicas, durability guarantees, and operational concerns for running Kafka in production.

Streaming Kafka
Apache Kafka Reliability and Operations

What Can Go Wrong

In production, brokers crash, network partitions happen, disks fill up. Kafka’s reliability story is built on one mechanism: replication. Every partition can have multiple copies across brokers. When one broker fails, another takes over. The details of how this works — and how to configure it correctly — determine whether you lose data or not.

Replication

Each partition has one leader and zero or more followers. Producers always write to the leader. Followers replicate the leader’s log by fetching new records continuously.

Topic: user-events, Partition 0 (replication-factor: 3)

Leader:   Broker 1  ← producers write here
Follower: Broker 2  ← replicates from Broker 1
Follower: Broker 3  ← replicates from Broker 1

Consumers read from the leader (or followers with replica.selector.class)

A replication factor of 3 is the standard recommendation for production: the cluster tolerates losing one broker without any data loss or unavailability. With replication factor 2, losing one broker causes unavailability (not enough replicas for min.insync.replicas=2).

In-Sync Replicas (ISR)

Not all followers stay perfectly caught up. The ISR (in-sync replicas) is the set of replicas that are within replica.lag.time.max.ms of the leader. Replicas that fall behind (due to network issues or slow I/O) are removed from the ISR.

The ISR is critical for durability. When a producer uses acks=all, the broker waits for all ISR members to acknowledge the record before responding. If a follower is not in the ISR, it is not waited on — this prevents a slow replica from blocking producers indefinitely.

# broker config
replica.lag.time.max.ms=10000    # follower removed from ISR if 10s behind
min.insync.replicas=2            # minimum ISR size for acks=all writes to succeed

With min.insync.replicas=2 and replication.factor=3:

  • Normal operation: 3 ISR members, all writes succeed
  • One broker fails: 2 ISR members, writes still succeed
  • Two brokers fail: 1 ISR member, writes fail with NotEnoughReplicasException — protecting durability over availability

Leader Election

When a leader broker fails, Kafka automatically elects a new leader from the ISR. Only ISR members are eligible — this ensures the new leader has all committed records.

If the ISR shrinks to zero (all replicas are behind), Kafka must choose between:

  • Wait for an ISR member to recover (data safety, but unavailability)
  • Elect an out-of-sync replica (availability, but potential data loss)

This is controlled by unclean.leader.election.enable:

# Default: false (safe — prefer data loss prevention over availability)
unclean.leader.election.enable=false

Leave this as false for any topic where data loss is unacceptable. Set to true only for topics where availability matters more than correctness (e.g., metrics, logs).

Durability Configuration Checklist

For a durable production topic:

# Topic level
replication.factor=3
min.insync.replicas=2

# Broker level
unclean.leader.election.enable=false
log.flush.interval.messages=10000   # or rely on OS page cache (usually fine)

# Producer level (in your app)
acks=all
enable.idempotence=true
retries=2147483647

The combination of acks=all, min.insync.replicas=2, and replication.factor=3 gives you the strongest durability guarantee Kafka offers.

Monitoring Key Metrics

Under-replicated partitions — partitions where the ISR is smaller than the replication factor. Any non-zero value means a broker is behind or down.

kafka.server:type=ReplicaManager,name=UnderReplicatedPartitions

Controller count — exactly one broker is the controller at a time. If this is not 1, there is a problem.

Consumer group lag — the difference between the latest offset in a partition and the consumer’s current offset. Rising lag means the consumer is falling behind.

# Check consumer group lag
kafka-consumer-groups.sh \
  --bootstrap-server kafka:9092 \
  --describe \
  --group analytics-service

Request latency — RequestHandlerAvgIdlePercent should be above 30%. If request handlers are consistently busy, the broker is under-provisioned.

Topic Configuration for Operations

# Alter topic config without downtime
kafka-configs.sh --alter \
  --entity-type topics \
  --entity-name user-events \
  --add-config retention.ms=604800000 \
  --bootstrap-server kafka:9092

# Increase partition count (cannot decrease)
kafka-topics.sh --alter \
  --topic user-events \
  --partitions 12 \
  --bootstrap-server kafka:9092

Disk and Retention Management

Kafka uses local disk for log segments. Monitor:

  • Disk usage per broker: should stay below 70% to allow for log compaction and temporary spikes
  • Log segment count: high segment counts slow down broker startup
  • Retention policy: set log.retention.hours and log.retention.bytes per topic based on replay needs vs storage cost

For topics that need indefinite retention of the latest value per key, use log compaction:

cleanup.policy=compact
min.cleanable.dirty.ratio=0.5

Key Takeaways

  • Set replication.factor=3 and min.insync.replicas=2 for production durability
  • The ISR tracks which replicas are in sync — acks=all waits for all ISR members
  • Keep unclean.leader.election.enable=false to prevent data loss during leader failover
  • Monitor under-replicated partitions and consumer group lag as primary health signals
  • Partition count can be increased but never decreased — plan ahead
