Apache Pekko Series, Part 5: HTTP with Pekko

HTTP is how most services talk to the world. Pekko HTTP is not a framework — it is a toolkit. There is no dependency injection container, no magic annotations, no hidden conventions. Just a routing DSL, a streaming HTTP layer built on Pekko Streams, and full control over every request and response.

Setup

val PekkoHttpVersion = "1.1.0"

libraryDependencies ++= Seq(
  "org.apache.pekko" %% "pekko-http"            % PekkoHttpVersion,
  "org.apache.pekko" %% "pekko-http-spray-json" % PekkoHttpVersion,  // JSON support
  "org.apache.pekko" %% "pekko-stream"          % PekkoVersion
)

The Routing DSL

Routes are built by composing directives — functions that either match a request (and handle it) or reject it (passing to the next alternative):

import org.apache.pekko.http.scaladsl.server.Directives._
import org.apache.pekko.http.scaladsl.server.Route

val route: Route =
  pathPrefix("api" / "v1") {
    concat(
      // GET /api/v1/items
      path("items") {
        get {
          complete("[]")
        }
      },
      // GET /api/v1/items/:id
      path("items" / Segment) { id =>
        get {
          complete(s"""{"id": "$id"}""")
        }
      },
      // POST /api/v1/items
      path("items") {
        post {
          entity(as[String]) { body =>
            complete(StatusCodes.Created, body)
          }
        }
      }
    )
  }

Directives compose with concat (try alternatives), ~ (alias for concat), and nesting (AND semantics). If a directive rejects, the next alternative is tried. If all alternatives reject, a 404 or 405 is returned.

Starting the Server

import org.apache.pekko.actor.typed.ActorSystem
import org.apache.pekko.actor.typed.scaladsl.Behaviors
import org.apache.pekko.http.scaladsl.Http

object Main extends App {
  implicit val system: ActorSystem[Nothing] =
    ActorSystem(Behaviors.empty, "pekko-http-server")
  implicit val ec = system.executionContext

  val bindingFuture = Http().newServerAt("0.0.0.0", 8080).bind(route)

  bindingFuture.foreach { binding =>
    println(s"Server online at http://localhost:8080/")
  }
}

JSON Marshalling

Pekko HTTP uses marshallers to convert between Scala types and HTTP entities. With pekko-http-spray-json:

import org.apache.pekko.http.scaladsl.marshallers.sprayjson.SprayJsonSupport._
import spray.json._
import spray.json.DefaultJsonProtocol._

case class Item(id: String, name: String, price: Double)

// Derive JSON format automatically
implicit val itemFormat: RootJsonFormat[Item] = jsonFormat3(Item)

val route: Route =
  path("items") {
    get {
      // Scala value → JSON response automatically
      complete(Item("1", "Widget", 9.99))
    } ~
    post {
      // JSON request body → Scala value automatically
      entity(as[Item]) { item =>
        println(s"Received: $item")
        complete(StatusCodes.Created, item)
      }
    }
  }

The complete(item) call uses the implicit itemFormat to serialize to application/json. entity(as[Item]) uses it to deserialize from the request body.

Integrating with Actors

The most common pattern is the ask pattern — the HTTP handler asks an actor for a result and returns the future as the response:

import org.apache.pekko.actor.typed.{ActorRef, ActorSystem}
import org.apache.pekko.actor.typed.scaladsl.AskPattern._
import org.apache.pekko.util.Timeout

implicit val timeout: Timeout = 5.seconds

// Assume we have a registry actor
val registry: ActorRef[ItemRegistry.Command] = ...

val route: Route =
  path("items" / Segment) { id =>
    get {
      val responseFuture: Future[Option[Item]] =
        registry.ask(ItemRegistry.FindById(id, _))

      onSuccess(responseFuture) {
        case Some(item) => complete(item)
        case None       => complete(StatusCodes.NotFound)
      }
    }
  }

onSuccess unwraps a Future and runs the inner route with the value. If the future fails (e.g., actor timeout), it returns a 500 automatically.

Error Handling

Use handleExceptions or handleRejections to provide consistent error responses:

import org.apache.pekko.http.scaladsl.server.ExceptionHandler

implicit val exceptionHandler: ExceptionHandler = ExceptionHandler {
  case ex: IllegalArgumentException =>
    complete(StatusCodes.BadRequest, ex.getMessage)
  case ex: Exception =>
    complete(StatusCodes.InternalServerError, "Internal error")
}

val route: Route = handleExceptions(exceptionHandler) {
  // your routes here
}

Key Takeaways

• Routes are composed from directives — each directive either matches or rejects
• concat / ~ try alternatives; nesting adds AND conditions
• complete(value) uses implicit marshallers to serialize the response
• entity(as[T]) uses implicit unmarshallers to deserialize the request body
• The ask pattern (actorRef.ask) bridges HTTP handlers to actors cleanly
• onSuccess(future) unwraps a Future inside a route without blocking

Next: gRPC with Pekko
